Applications
- TM(LF)-100 for non-viscous liquid, e.g. oil, makeup, toner, moisturizing fluidity, cleansing water etc.
- TM(LF)-1000 and TM(LF)-5000 is for viscous liquid and paste sauce, e.g. Shampoo, shower gel, skin lotion, cream etc.
Features
- Integrated control system powered by micro-processor.
- Stainless steel construction, durable in use.
- Sasy-dismantle design makes cleaning easier.
- Stepless filling volume adjustment.
- Semi-auto footstep switch and fully automatic operation selectable.
- Capable of integration to production line easily.
- LF 100 pump is driven by magnetic motor, with self-priming function.
- LF 1000 and LF 5000 pump is driven by servo motor, without self-priming function.
Specification
Model |
TM(LF)100 |
TM(LF)1000 |
TM(LF)5000 |
Filling range |
1-100ml |
10-1000ml |
30-5000ml |
Type of pump |
Magnetic |
Compact gear |
Triaster rotator |
Accuracy |
±0.3-1% |
±1-1.5% |
±1-2% |
Filling speed |
5-20 pieces max* |
||
Max liquid temperature |
50 |
80 |
80 |
Power consumption |
100W |
370W |
550 |
Weight |
16kg |
19kg |
80kg |
